0606 P23 - Jun 2024 - Q10 - 7 marks
7492

The diagram shows a parallelogram \(O A B C\). The point \(D\) divides the line \(O C\) in the ratio \(2: 3\). \(\overrightarrow{O A}=\mathbf{a} \text { and } \overrightarrow{O C}=\mathbf{c}\)

The point \(P\) lies on \(A D\) such that \(\overrightarrow{O P}=\lambda \overrightarrow{O B}\) and \(\overrightarrow{A P}=\mu \overrightarrow{A D}\), where \(\lambda\) and \(\mu\) are scalars. Find two expressions for \(\overrightarrow{O P}\), each in terms of \(\mathbf{a}\), \(\mathbf{c}\) and a scalar, and hence show that \(P\) divides both \(D A\) and \(O B\) in the ratio \(m: n\), where \(m\) and \(n\) are integers to be found.

0606_s24_qp_23_q10 problem diagram
