9709 P42 - Nov 2013 - Q2
3604
A box of mass 25 kg is pulled in a straight line along a horizontal floor. The box starts from rest at a point A and has a speed of 3 m/s when it reaches a point B. The distance AB is 15 m. The pulling force has magnitude 220 N and acts at an angle of \(\alpha^\circ\) above the horizontal. The work done against the resistance to motion acting on the box, as the box moves from A to B, is 3000 J. Find the value of \(\alpha\).
